Stainless Steel Hydraulic Fittings

Home > Stainless Steel > Stainless Steel Hydraulic Fittings

Nestled in the industrious city of Hamilton, New Zealand, Mason Tubefittings stands as a dedicated source for precision-engineered stainless steel hydraulic components. We understand that the integrity of your systems relies on the quality of every connection, which is why our focus is on providing fittings built to endure. Serving a diverse range of local and international industries, our commitment is to offer not just a product, but a reliable partnership, ensuring your operations benefit from superior performance and lasting durability right here from the heart of the Waikato.

SS Equal Hydraulic Tee Fittings Manufacturer in Wellington, Stainless Steel Hydraulic Equal Elbow Fittings Exporter in Tauranga, Stainless Steel Hydraulic Equal Cross Hydraulic Fittings in Hamilton, New Zealand, SS Hydraulic Female Stud Coupling Manufacturer in Auckland, Stainless Steel Hydraulic Straight Coupling in Dunedin, Stainless Steel Hydraulic Tube Fittings Supplier in Hamilton, Stainless Steel Hydraulic Male Stud Coupling Price List in Tauranga

The exceptional strength of our stainless steel hydraulic fittings comes from a carefully selected composition, primarily chromium and nickel, which gives them their renowned corrosion resistance. This material is further enhanced to achieve excellent mechanical properties, including high tensile strength and impressive durability under significant pressure. These characteristics ensure the fittings can withstand not just the demands of high-pressure hydraulic systems but also resist wear from vibration and mechanical shock, providing a combination of toughness and longevity that is essential for critical applications.

Stainless Steel Hydraulic Fittings Specifications

DESIGN STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , SS 310, SS 347
MATERIAL
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
CONNECTIONS	TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE
CONNECTIONS	WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL
BODY TYPE	FORGED, BAR STOCK
SURFACE	STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH
TEMPERATURE	(-60C TO 400C)

APPLICATIONS & INDUSTRIES	CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT
MATERIAL DESIGNATOR	STAINLESS STEEL – ASTM A 276 , ASTM 182

Stainless Steel Hydraulic Fittings Chemical Composition

Type	Grade		ASTM A240 Chemical Composition
Type	ASTM(A240M)	Others(JIS)	C	Si	Mn	P	S	Ni	Cr	Mo	Others
Stainless Steels	304	SUS304	≤0.07	≤0.75	≤2.00	≤0.045	≤0.030	8.0/10.5	17.5/19.5	―	N≤0.10
	304H		0.04/0.10	≤0.75	≤2.00	≤0.045	≤0.030	8.0/10.5	18.0/20.0	―
	304L	SUS304L	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	8.0/12.0	17.5/19.5	―	N≤0.10
	304N	SUS304N1	≤0.08	≤0.75	≤2.00	≤0.045	≤0.030	8.0/10.5	18.0/20.0	―	N:0.10/0.16
	304LN	SUS304LN	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	8.0/12.0	18.0/20.0	―	N:0.10/0.16
	309S	SUS309S	≤0.08	≤0.75	≤2.00	≤0.045	≤0.030	12.0/15.0	22.0/24.0	―
	310S	SUS310S	≤0.08	≤1.50	≤2.00	≤0.045	≤0.030	19.0/22.0	24.0/26.0	―
	316	SUS316	≤0.08	≤0.75	≤2.00	≤0.045	≤0.030	10.0/14.0	16.0/18.0	2.00/3.00	N≤0.10
	316L	SUS316L	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	10.0/14.0	16.0/18.0	2.00/3.00	N≤0.10
	316H		0.04/0.10	≤0.75	≤2.00	≤0.045	≤0.030	10.0/14.0	16.0/18.0	2.00/3.00
	316LN	SUS316LN	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	10.0/14.0	16.0/18.0	2.00/3.00	N:0.10/0.16
	317L	SUS317L	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	11.0/15.0	18.0/20.0	3.0/4.0	N≤0.10
	317LN	SUS317LN	≤0.030	≤0.75	≤2.00	≤0.045	≤0.030	11.0/15.0	18.0/20.0	3.0/4.0	N:0.10/0.22
	321	SUS321	≤0.08	≤0.75	≤2.00	≤0.045	≤0.030	9.0/12.0	17.0/19.0	―	N≤0.10Ti:5ʷʢC+Nʣ/0.70
	347	SUS347	≤0.08	≤0.75	≤2.00	≤0.045	≤0.030	9.0/13.0	17.0/19.0	―	Nb:10ʷC/1.00
	904L	SUS890L	≤0.020	≤1.00	≤2.00	≤0.045	≤0.035	23.0/28.0	19.0/23.0	4.00/5.00	N≤0.10Cu:1.0/2.0
	S31254		≤0.020	≤0.80	≤1.00	≤0.030	≤0.010	17.5/18.5	19.5/20.5	6.0/6.5	N:0.18/0.25Cu:0.50/1.00
		SUS317J2	≤0.06	≤1.50	≤2.00	≤0.045	≤0.030	12.00/16.00	23.00/26.00	0.50/1.20	N:0.25/0.40

Stainless Steel Hydraulic Fittings Mechanical Properties

Type	Mechanical Properties for Stainless Steel Plates
	ASTM(A240M)	Others(JIS)	Tensile Properties			Hardness
	ASTM(A240M)	Others(JIS)	Yield Strength (Mpa)	Tensile Strength (Mpa)	Elongation (%)	HBW	HRBW
AusteniticSteels	304	SUS304	≥205	≥515	≥40	≤201	≤92
	304H		≥205	≥515	≥40	≤201	≤92
	304L	SUS304L	≥170	≥485	≥40	≤201	≤92
	304N	SUS304N1	≥240	≥550	≥30	≤217	≤95
	304LN	SUS304LN	≥205	≥515	≥40	≤217	≤95
	309S	SUS309S	≥205	≥515	≥40	≤217	≤95
	310S	SUS310S	≥205	≥515	≥40	≤217	≤95
	316	SUS316	≥205	≥515	≥40	≤217	≤95
	316L	SUS316L	≥170	≥485	≥40	≤217	≤95
	316H		≥205	≥515	≥40	≤217	≤95
	316LN	SUS316LN	≥205	≥515	≥40	≤217	≤95
	317L	SUS317L	≥205	≥515	≥40	≤217	≤95
	317LN	SUS317LN	≥240	≥550	≥40	≤217	≤95
	321	SUS321	≥205	≥515	≥40	≤217	≤95
	347	SUS347	≥205	≥515	≥40	≤201	≤92
	N08904/904L	SUS890L	≥220	≥490	≥35	≤196	≤90
	S31254		≥310	≥655	≥35	≤223	≤96
		SUS317J2	≥345	≥690	≥40	≤250	≤100

Top Stainless Steel Hydraulic Fittings Manufacturing Company in Hamilton

At Mason Tube Fittings, we are the largest supplier, manufacturer, and exporter of Stainless Steel Hydraulic Fittings in Hamilton, New Zealand. Our advanced manufacturing facilities, strategically positioned in the New Zealand, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Stainless Steel Hydraulic Fittings

SS Hydraulic Straight Coupling in Hamilton, New Zealand, Hydraulic Stainless Steel Bulkhead Union Price in Hamilton, SS Hydraulic Banjo Elbow Supplier in Tauranga, Hydraulic Stainless Steel Swivel Fittings Manufacturer in Auckland, SS Hydraulic Male Stud Coupling Price in Dunedin, SS Equal Cross Hydraulic Fittings Tube Fittings Supplier And Manufacturer in Wellington

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Stainless Steel Hydraulic Fittings in Hamilton, New Zealand

Mason Tube Fittings is a leading supplier and stockist of premium Stainless Steel Hydraulic Fittings in Hamilton, New Zealand. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Stainless Steel Hydraulic Fittings Uses

The robust nature of stainless steel hydraulic fittings makes them indispensable in environments where failure is not an option. You will find them safeguarding operations in food and beverage production, where hygiene and cleanliness are critical, and in chemical processing plants where they resist aggressive media. They are equally vital in marine applications, fighting off saltwater corrosion, and in heavy machinery across agriculture, mining, and construction, ensuring reliable power transmission in the toughest conditions, from dusty outbacks to wet, challenging worksites.
