Hydraulic Weldable Nipple

Home > Hydraulic Weldable Nipple

Monib Stainless is a trusted manufacturer and supplier located in Safat, Kuwait, known for its top-notch Hydraulic Weldable Nipples that ensure secure and leak-free hydraulic connections. Crafted with cutting-edge techniques and rigorous quality control, these nipples promise outstanding strength, precision, and a long lifespan. Monib Stainless meets the needs of various sectors, including hydraulic, industrial, and engineering, providing products that excel under high pressure and challenging conditions. With a commitment to reliability, timely delivery, and customer satisfaction, Monib Stainless has established itself as a go-to source for durable hydraulic fittings throughout Kuwait and beyond.

Hydraulic Weld Nipple Manufacturer in Hamilton, Reducing Weld Nipple Supplier in Tauranga, New Zealand, Weld nipple fittings Exporter in Dunedin, Hydraulic Weld Nipple Supplier in Hamilton, Reducing Weld Nipple Exporter in Auckland, Weld nipple fittings Stockist in Wellington, Hydraulic Weld Nipple Distributor in Tauranga, New Zealand

Hydraulic Weldable Nipples are generally made from carbon steel, alloy steel, or stainless steel, depending on what the application calls for. Typical compositions include iron mixed with specific amounts of carbon, manganese, chromium, nickel, and molybdenum to boost strength and resist corrosion. These materials offer high tensile and yield strength, impressive toughness, and good weldability. The fittings are designed to withstand internal pressure, vibration, and mechanical stress, ensuring dependable performance in hydraulic systems that operate under high pressure and varying load conditions.

Hydraulic Weldable Nipple Specifications

STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	MS, CS, SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , BRASS , COPPER , DUPLEX , SUPER DUPLEX , INCONEL , MONEL , HASTELLOY , 904L , 6MO, TITANIUM , ALUMNIUM, ALLOY 20
MATERIAL
SERIES	LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
BODY TYPE	BAR STOCK
ACCESSORIES	O-RING
O-RING & SEALS	NBR ( -35C TO 100 C ) VITON (-25C TO 200 C)
SURFACE	CARBON STEEL – BLACK PHOSPHATED
SURFACE	STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH
TEMPERATURE	STEEL – (-40* C TO 120C) ,STAINLESS STEEL – (-60C TO 400C) BRASS – (-60C TO 175*C)
MATERIAL DESIGNATOR	STAINLESS STEEL – ASTM A 276 , ASTM 182
	STEEL – ASTM 108/A105, JIS G4051 S20C, S45C,/G3201 SF440A.
	BRASS – ASTM B16 UNS C36000 , ASTM B282 ALLOY 37700 , JIS H3250 C3604 , C3771 , JIS H3250 C3771.

Top Hydraulic Weldable Nipple Manufacturing Company in Hamilton

At Mason Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Weldable Nipple in Hamilton, New Zealand. Our advanced manufacturing facilities, strategically positioned in the New Zealand, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Hydraulic Weldable Nipple

Hydraulic Weldable Nipple Dimensions

Outer Diameter (mm)	To Fit Tube Size (mm)	d1 (mm)	L (mm)	O-Ring (mm)	Max. Pressure (bar)
8	8 x 2	4	31	6 x 1.5	400
10	10 x 1.5	–	–	–	400
10	10 x 2	6	32.5	7.5 x 1.5	315
12	12 x 2.5	6	32.5	9 x 1.5	400
16	16 x 2	–	–	–	400
16	16 x 3	10	38.5	12 x 2	400
20	20 x 3	14	44.5	16.3 x 2.4	250
25	25 x 3	19	49.5	20.3 x 2.4	250
25	25 x 4	17	49.5	20.3 x 2.4	315
30	30 x 4	22	52	25.3 x 2.4	250
30	30 x 5	20	52	25.3 x 2.4	315
38	38 x 4	30	56.5	33.3 x 2.4	160
38	38 x 5	28	56.5	33.3 x 2.4	250
38	38 x 6	26	56.5	33.3 x 2.4	315

Hydraulic Reducing Weld Nipple Manufacturer in Hamilton, Hydraulic Reducing Weldable Nipple Supplier in Dunedin, Hydraulic Welding Nipple Exporter in Auckland, Hydraulic Reducing Weld Nipple Exporter in Hamilton, Hydraulic Reducing Weldable Nipple Stockist in Hamilton,New Zealand, Hydraulic Welding Nipple Distributor in Tauranga, New Zealand, Hydraulic Reducing Weldable Nipple Manufacturer in Wellington

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Hydraulic Weldable Nipple in Hamilton, New Zealand

Mason Tube Fittings is a leading supplier and stockist of premium Hydraulic Weldable Nipple in Hamilton, New Zealand. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Hydraulic Weldable Nipple Uses

Hydraulic Weldable Nipples are commonly used to connect pipes, tubes, and hydraulic lines through permanent welded joints. You’ll find them in hydraulic power units, oil and gas pipelines, heavy machinery, construction equipment, and industrial fluid transfer systems. These fittings are also essential in petrochemical plants, marine installations, and manufacturing facilities where high-pressure and leak-proof connections are crucial. Thanks to their robust weldability and reliability, they play a vital role in ensuring the smooth operation of various hydraulic applications.
