From its base in Hamilton, New Zealand, Mason Tubefittings combines local craftsmanship with precision engineering to deliver robust solutions for demanding industries. Our Adjustable Locknut Elbow is a perfect example of this commitment, designed to simplify complex installations. We understand that in the real world, pipes aren’t always perfectly aligned, which is why we’ve created a fitting that offers both exceptional strength and the flexibility needed to tackle the unexpected challenges on the job site, saving you valuable time and effort.

45 Degree Hydraulic Adjustable Elbow Supplier in Hamilton, 45 Degree Swivel Elbow Price List in Tauranga, C.s Adjustable Elbow Stand Pipe Manufacturer in Auckland, Din Swivel Elbow In Dunedin, Male Jic X Female Swivel Elbow Exporter in Tauranga, Ss Swivel Adjustable Elbow Manufacturer in Wellington, Cs Swive Elbow In Hamilton, New Zealand.

The heart of this fitting lies in its thoughtful construction, typically crafted from durable, corrosion-resistant materials like stainless steel or brass to ensure a long service life. Its design focuses on superior mechanical performance, featuring a secure locknut mechanism that eliminates the risk of loosening under vibration or pressure changes. This results in a fitting that not only provides a leak-proof seal but also maintains its precise angular adjustment, offering a reliable and permanent connection you can trust in even the most rigorous applications.

Adjustable Locknut Elbow Specifications

STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	MS, CS, SS 304, SS 304L, SS 316, SS 316L, SS 316TI ( 1.4571), BRASS, COPPER, DUPLEX, SUPER DUPLEX, INCONEL, MONEL, HASTELLOY, 904L, 6MO, TITANIUM, ALUMINUM, ALLOY 20
MATERIAL
SERIES	LL- LOW PRESSURE, L- MEDIUM PRESSURE, S- HIGH PRESSURE
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
BODY TYPE	FORGED, BAR STOCK
ACCESSORIES	O-RING, DOWTY SEAL, COPPER WASHER, ED SEAL, CUTTING RING, NUT
O-RING & SEALS	NBR ( -35C TO 100 C ) VITON (-25C TO 200 C) , PTFE – (-60C TO 240)
SURFACE	CARBON STEEL -TRIVALENT ZINC PLATED, YELLOW PLATTING, BLACK PHOSPHATE,
SURFACE	STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH
TEMPERATURE	STEEL – (-40* C TO 120C) ,STAINLESS STEEL – (-60C TO 400C) BRASS – (-60C TO 175*C)

Top Adjustable Locknut Elbow Manufacturing Company in Hamilton

At Mason Tube Fittings, we are the largest supplier, manufacturer, and exporter of Adjustable Locknut Elbow in Hamilton, New Zealand. Our advanced manufacturing facilities, strategically positioned in the New Zealand, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Adjustable Locknut Elbow

Adjustable Locknut Elbow Technical Data

Series	Tube ?D1	F1	F	L	A	L1	P
L	6	14	12	27	12	26	M 12 x 1.5
light	8	17	12	29	14	27.5	M 14 x 1.5
PN 315	10	19	14	30	15	29	M 16 x 1.5
	12	22	17	32	17	29.5	M 18 x 1.5
	15	27	19	36	21	32.5	M 22 x 1.5
	18	32	24	40	23.5	35.5	M 26 x 1.5
PN 160	22	36	27	44	27.5	38.5	M 30 x 2
	28	41	36	47	30.5	41.5	M 36 x 2
	35	50	41	56	34.5	51	M 45 x 2
	42	60	50	63	40	56	M 52 x 2
S	6	17	12	31	16	27	M 14 x 1.5
heavy	8	19	14	32	17	27.5	M 16 x 1.5
PN 630	10	22	17	34	17.5	30	M 18 x 1.5
	12	24	17	38	21.5	31	M 20 x 1,5
	14	27	19	40	22	35	M 22 x 1.5
PN 400	16	30	24	43	24.5	36.5	M 24 x 1.5
	20	36	27	48	26.5	44.5	M 30 x 2
	25	36	36	54	30	50	M 36 x 2
	30	50	41	62	35.5	55	M 42 x 2
PN 315	38	60	50	72	41	63	M 52 x 2

45 Degree Hydraulic Adjustable Elbow Exporter in Hamilton, C.s Adjustable Elbow Stand Pipe Price List in Tauranga, 45 Degree Swivel Elbow Manufacturer in Auckland, Din Swivel Elbow In Dunedin, Male Jic X Female Swivel Elbow Supplier in Tauranga, Ss Swivel Adjustable Elbow Manufacturer in Wellington, Cs Swive Elbow In Hamilton, New Zealand.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Adjustable Locknut Elbow Supplier in Hamilton, New Zealand

Mason Tube Fittings is a leading supplier and stockist of premium Adjustable Locknut Elbow in Hamilton, New Zealand. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Adjustable Locknut Elbow Uses

The primary advantage of this elbow is its ability to compensate for minor misalignments in piping systems, making it indispensable for both new installations and repairs. You’ll find it incredibly useful in industrial machinery, hydraulic and pneumatic setups, and processing plants where perfect angles are often hard to achieve. It simplifies the work for engineers and technicians, allowing for quick adjustments without the need for custom bends or complex assemblies, ultimately enhancing efficiency and reducing downtime across a wide range of projects.
